7/3	Unknown Responses	[1] 5.1.4, 2.4 2	M
7/4	Requesting Feature Setup	[1] 5.1.4.1	M
7/4a	Responding in Feature Setup	[1] 5.1.4.2	C.18		C.18: Mandatory IF LL 9/5 "Peripheral-initiated Features Exchange", otherwise Excluded.
7/5	Sending Data (Device supports data output from a Host)	[1] 4.5.1, 4.5.6	M
7/6	Receiving Data (Device supports data input to a Host)	[1] 4.5.1, 4.5.6	M
7/7	More Data	[1] 4.5.6	O
7/10	Requesting Parameter Update	[1] 5.1.1	M
7/10a	Initiating Connection Parameter Request	[1] 5.1	C 2		C 2: Mandatory IF LL 9/3 "Connection Parameters Request Procedure", otherwise Excluded.
7/10b	Accepting Connection Parameter Request	[1] 5.1	C 2		C 2: Mandatory IF LL 9/3 "Connection Parameters Request Procedure", otherwise Excluded.
7/11	Requesting Channel Map Update	[1] 5.1 2	M
7/12	Encryption Start	[1] 5.1.3	C.17		C.17: Mandatory IF LL 9/1 "LE Encryption", otherwise Excluded.
7/13	Connection Control Timer	[1] 5.2	M
7/14	Sending Termination	[1] 5.1.6	M
7/15	Accepting Termination	[1] 5.1.6	M
7/16	Connection Supervision Timer	[1] 4.5 2	M
7/19	Central Pause Encryption	[1] 5.1.3	C.17		C.17: Mandatory IF LL 9/1 "LE Encryption", otherwise Excluded.
7/20	Central Version Exchange	[1] 5.1.5	M
7/22	Data Length Update Procedure	[3] 5.1.9	C.4		C.4: Mandatory IF LL 9/6 "LE Data Packet Length Extension", otherwise Excluded.
7/23a	PHYUpdate	[4] 5.1.10	C.9		C.9: Excluded IF SUM ICS 21/14 "Core v4 .2", otherwise Mandatory IF LL 9/6a "Multiple PHYs",
	procedure				otherwise Optional.
7/29	Sending Long Control PDUs	[6] 4.5.11	C.13		C.13: Mandatory IF (LL 7/26 "Initiating Periodic Advertising Sync Transfer Procedure for Local Periodic Advertising" OR LL 7/27 "Initiating Periodic Advertising Sync Transfer Procedure for Remote Periodic Advertising" OR LL 9/31 "Connected Isochronous Stream Central"), otherwise Excluded.

Table 8: Physical Channels

Item Capability Reference Supp。rt Status C。mment
8/1 General-purpose [1] 1.4.1 C.1 C.1: Mandatory IF LL 1/4 "Peripheral Role" OR LL 1/5 "Central Role" OR LL 1/6 "Isochronous
channels Broadcasting State" OR LL 3/9 "Extended Advertising", otherwise Excluded.
8/2 PrimaryAdvertising [1] 1.4.1 M ~~ ~~
channels
8/3 Support Data channel [1] 4.5.8 C 2 v C 2: Mandatory IF LL 1/4 "Peripheral Role" OR LL 1/5 "Central Role" OR LL 9/10 "Channel
selection algorithm Selection Algorithm #2", otherwise Excluded.

Table 9: Supp。rted Features

Item Capability Reference Supp。rt Status C。mment
9/1 LE Encryption [1] 4.6.1 O

9/3 Connection Parameters Request Procedure [1] 4.6 2 C.2 C.2: Optional IF LL 9/4 "Extended Reject Indication", otherwise Excluded.
xen e e ec
Indication
9/5 Peri heral-initiated [1] 4 6 4 O
Features
Exchange
a a ac e
Length Extension
9/6a Multiple PHYs [4] 4.6.9 C.6 C.6: Mandatory IF LL 9/7 "LE 2MPHY" OR LL 9/9 "LE Coded PHY", otherwise Excluded.
9/7 LE 2MPHY [3] 2 1 C 5 C 5: Excluded IF SUM ICS 21/14 "Core v4 2" otherwise O tional IF LL 9/4 "Extended Reject Indication"
otherwise Excluded.
9/8 As mmetric [4] 4 6 9 1 C 7 C 7: O tional IF LL 9/6a "Multi le PHYs" otherwise Excluded
Connections
Algorithm #2
9/30 Sleep Clock [6] 4.6 25 C.37 C.37: Excluded IF SUMICS 21/14 "Core v4 2" OR SUMICS 21/16 "Core v5 .0" otherwise Optional.
Accuracy Updates
9/31 Connected [7] 4 6 27 C 28 C 28: Excluded IF SUM ICS 21/18 "Core v5 1" otherwise Optional IF LL 1/5 "Central Role" AND LL 9/4
Isochronous "Extended Reject Indication" AND LL 9/10 "Channel Selection Algorithm #2" AND LL 9/30 "Sleep Clock
Stream Central Accuracy Updates", otherwise Excluded.
Isochronous 9/4 "Extended Reject Indication" AND LL 9/10 "Channel Selection Algorithm #2" AND LL 9/30 "Sleep
Stream Peripheral Clock Accuracy Updates", otherwise Excluded.
Broadcaster 9/42 "Periodic Advertising", otherwise Excluded.
Receiver 9/42 "Periodic Advertising", otherwise Excluded.
9/35 ISO Receive Test [8] 7 8 112 C 32 C 32: Mandatory IF LL 9/31 "Connected Isochronous Stream Central" OR LL 9/32 "Connected
7.8.113, Isochronous Stream Peripheral" OR LL 9/34 "Synchronized Receiver", otherwise Excluded.
7.8.114
7.8.114 Isochronous Stream Peripheral" OR LL 9/33 "Isochronous Broadcaster", otherwise Excluded.
9/41 Extended [6] 4 6 12 C 38 v C 38: Excluded IF SUM ICS 21/14 "Core v4 2" otherwise Optional IF LL 9/10 "Channel Selection
Advertising Algorithm #2", otherwise Excluded IF LL 1/4 "Peripheral Role" OR LL 1/5 "Central Role", otherwise
Optional.
Advertising otherwise Excluded.
9/43 Periodic [10] 4 6 34 C 40 C 40: Excluded IF SUMICS21/16 "Core v5 0" OR SUMICS21/18 "Core v5 1" OR SUMICS21/20 "Core
Advertising ADI v5 .2", otherwise Optional IF LL 9/42 "Periodic Advertising", otherwise Excluded.
support
9/46 BN values greater [7] 4.5.13.1 C.42 C.42: Optional IF (LL 9/31 "Connected Isochronous Stream Central" OR LL 9/32 "Connected than 1 in CIS Isochronous Stream Peripheral"), otherwise Excluded.
9/47 FT values greater [7] 4.5.13.1 C.42 than 1 in CIS Table 10: Scatternet Capabilities v C.42: Optional IF (LL 9/31 "Connected Isochronous Stream Central" OR LL 9/32 "Connected Isochronous Stream Peripheral"), otherwise Excluded.
Item Capability Reference Support Status Comment

9/4 E
t
d
d R
j
t
[1] 4.6.3 O
p
.
.
9/6 LE D
t
P
k
t
[3] 4.6.6 O
.
.
.
.
,
p
,
y
.
.
.
.
.
p
p
,
.
9/10 Channel Selection
[4] 4.6.14 C.10
C.10: Excluded IF SUM ICS 21/14 "Core v4 2", otherwise Optional.
,
.
.
.
.
,
9/32 Connected
[7] 4.6 27 C.29
v C.29: Excluded IF SUM ICS 21/18 "Core v5 .1", otherwise Optional IF LL 1/4 "Peripheral Role" AND LL
9/33 Isochronous
[7] 4.6 28 C.30
C.30: Excluded IF SUM ICS 21/16 "Core v5 .0" OR SUM ICS 21/18 "Core v5 .1", otherwise Optional IF LL
9/34 Synchronized
[7] 4.6 29 C.30
C.30: Excluded IF SUM ICS 21/16 "Core v5 .0" OR SUM ICS 21/18 "Core v5 .1", otherwise Optional IF LL
.
.
,
.
.
9/36 ISO Transmit Test [8] 7.8.111,
C.33
v C.33: Mandatory IF LL 9/31 "Connected Isochronous Stream Central" OR LL 9/32 "Connected
.
.
.
.
,
9/42 Periodic
[6] 4.6.13 C.39
C.39: Optional IF LL 9/41 "Extended Advertising" AND LL 9/10 "Channel Selection Algorithm #2",
.
.
.
.
.
.

Table 11: Protocol Synchronizing Features

Prerequisite: LL 1/3a "Synchronized State"

Item	Capability	Reference	Support	Status	Comment
11/1	Synchronizing to Periodic Advertising	[6] 4.4.3.4	C.3		C.3: Mandatory IF LL 4/8 "Scanning for Periodic Advertising", otherwise Excluded.
11/3	Receiving Data on Single Broadcast Isochronous Stream	[7] 4.4.5.2	C 2		C 2: Mandatory IF LL 9/34 "Synchronized Receiver", otherwise Excluded.

Table 11a: Synchronized Receiver Features

Prerequisite: LL 9/34 "Synchronized Receiver"

Item	Capability	Reference	Support	Status	Comment
11a/1	BN values greater than 1	[7] 4.4.6.3	O
11a/2	Pre-transmission	[7] 4.4.6.3	O

Table 12: Protocol Isochronous Broadcasting Features

Prerequisite: LL 1/6 "Isochronous Broadcasting State"

Item	Capability	Reference	Support	Status	Comment
12/1	Encrypted Broadcast Isochronous Stream	[7] 4.4.6.1, 4.4.6.10	C.1		C.1: Mandatory IF LL 9/1 "LE Encryption", otherwise Excluded.
12/2	Unencrypted Broadcast Isochronous Stream	[7] 4.4.6.1	M
12/3	Transmitting Data on Multiple Broadcast Isochronous Streams	[7] 4.4.6.3	O
12/4	BN values greater than 1	[7] 4.4.6.3	O
12/5	Pre-transmission	[7] 4.4.6.6	O

Link Manager Protocol

Table 1 : Response Messages

Item	Capability	Reference	Support	Status	Comment
1/1	Accept message	[1] 2.7	M
1/2	Reject message	[1] 2.7	M

Table 2: Supported Features

Item	Capability	Reference	Support	Status	Comment
2/1	3-slot packets	[1] 3.3, 4.1.10	O
2/2	5-slot packets	[1] 3.3, 4.1.10	O
2/3	Encryption	[1] 3.3, 4 2.5	M
2/4	Slot offset	[1] 3.3, 4.4.1	O
2/5	Timing accuracy	[1] 3.3, 4.3.1	O
2/6	Role switch	[1] 3.3, 4.4.2	C.5		C.5: Optional IF LMP 2/4 "Slot offset", otherwise Excluded.
2/8	Sniff mode	[1] 3.3, 4.5.3	O
2/10	Power Control	[1] 3.3, 4.1.3, [2] 3	C.1		C.1: Mandatory IF RF 1/1 "Power Class 1", otherwise Optional.
2/11	Channel quality driven data rate	[1] 3.3, 4.1.7	O
2/12	SCO link	[1] 3.3, 4.6.1	O
2/13	RSSI	[1] 3.3	O
2/13a	Power Control Requests	[1] 3.3, 4.1.3	O
2/15	eSCO link	[1] 4.6 2	O
2/17	Enhanced Data Rate	[3] 6.5.4,			C.2: Mandatory IF SUM ICS 22/1 "EDR for asynchronous transports (single slot)" OR SUM ICS 22/2
	ACL (2 Mb/s mode)	[1] 3.3			"EDR for asynchronous transports (multi-slot)" OR LMP 2/17a "Enhanced Data Rate ACL (3 Mb/s mode)" OR BB 5a/1 "2-DH1 packet type", otherwise Excluded.

C.2

2/17a	Enhanced Data Rate ACL (3 Mb/s mode)	[3] 1, 6.5.4,[1] 3.3	C.19		C.19: Mandatory IF BB 5a/4 "3-DH1 packet type", otherwise Excluded.
2/18	Enhanced Data Rate	[3] 6.5.3,	C.3		C.3: Mandatory IF SUM ICS 22/4 "EDR for synchronous transports (Core 3 .0 or later)" OR LMP
	eSCO(2 Mb/s mode)	[1] 3.3			2/18a "Enhanced Data Rate eSCO(3 Mb/s mode)" OR BB 6a/1 "2-EV3 packet type", otherwise Excluded.
2/18a	Enhanced Data Rate	[3] 1, 6.5.3,	C.20		C.20: Mandatory IF BB 6a/3 "3-EV3 packet type", otherwise Excluded.
	eSCO(3 Mb/s mode)	[1] 3.3
2/19a	Simple Pairing Updates	[6], [7] 4 2.7.4	M
2/19b	Secure Simple Pairing (Controller Support)	[1] 4.2.7	M
2/20	Enhanced Power	[1] 3.3,	C.6		C.6: Optional IF LMP 2/10 "Power Control" AND LMP 2/13a "Power Control Requests", otherwise
	Control	4.1.3.1			Excluded.
2/22	LE Supported (Controller)	[1] 3.3	O
2/23	LE and BR/EDR to same device capable (Controller)	[1] 3.3	C.12		C.12: Optional IF LMP 2/22 "LE Supported (Controller)", otherwise Excluded.
2/27	Ping	[4] 3.3, 4.1.13	O
2/30	Paging Parameter Negotiation	[1] 4.1.9	O

Table 3: Authentication

Item	Capability	Reference	Support Status Comment
3/2	Initiate authentication after connection completed	[1] 4 2.1	O
3/3	Respond to authentication request	[1] 4 2.1	M

Table 4: Pairing

Item	Capability	Reference	Support	Status	Comment
4/1	Initiate pairing before connection completed	[1] 4.4.2	O
4/2	Initiate pairing after connection completed	[1] 4.4.2	O
4/3	Respond to pairing request	[1] 4 2.2.1, 4 2.2.3	M
4/4	Use fixed PIN and request responder to initiator switch	[1] 4 2.2.2	C.1		C.1: Mandatoryto support at least one.
4/5	Use variable PIN	[1] 4 2.2.2	C.1		C.1: Mandatoryto support at least one.
4/6	Accept initiator to responder switch	[1] 4 2.2.2	C.2		C.2: Mandatory IF LMP4/5 "Use variable PIN" AND (LMP4/1 "Initiate pairing before connection completed" OR LMP 4/2 "Initiate pairing after connection completed"), otherwise Optional.
4/7	TSPC_Change_of_IO_Capabilities	[1] 4 2.7.3.4	M

Table 5: Link Keys

Item	Capability	Reference	Support	Status Comment
5/2	Creation of link key-Combination Key	[1] 4.2 2.4	M
5/3	Initiate change of link key	[1] 4.2.3	O
5/4	Accept change of link key	[1] 4.2.3	M
5/8	Support for 7 bytes or longer encryption keysize	[1] 4.2.5.2	M

Table 6: Encryption

Prerequisite: LMP 2/3 "Encryption"

Item	Capability	Reference	Support	Status Comment
6/1	Initiate encryption	[1] 4.2.5.1	M
6/2	Accept encryption requests	[1] 4.2.5.1	M
6/5	Keysize negotiation	[1] 4.2.5.2	M
6/6	Start encryption, as Central	[1] 4.2.5.3	M
6/7	Accept start of encryption	[1] 4.2.5.3	M
6/8	Stop encryption, as Central	[1] 4.2.5.4	M
6/9	Accept stop of encryption	[1] 4.2.5.4	M
6/10	Encryption Pause/Resume	[1] 4.2.5.3	M

Table 7: Clock Offset Information

Item	Capability	Reference	Support	Status	Comment
7/1	Request clock offset information	[1] 4.3 2	O
7/2	Respond to clock offset requests	[1] 4.3 2	M

Table 8: Slot Offset Information

Prerequisite: LMP 2/4 "Slot offset"
Item Capability Reference Support Status Comment
8/1 Send slot offset information [1] 4.4.1 C.1 C.1: Mandatory IF LMP 13/1 "Request role switch", otherwise Optional.

Table 9: Timing Accuracy Information

Prerequisite: LMP 2/5 "Timing accuracy"

Item	Capability	Reference	Support Status Comment
9/1	Request timing accuracy information	[1] 4.3.1	O
9/2	Respond to timing accuracy information requests	[1] 4.3.1	M

Table 10: LM Version Information

Item	Capability	Reference	Support Status Comment
10/1	Request LMversion information	[1] 4.3.3	O
10/2	Respond to LMversion information requests	[1] 4.3.3	M

Table 11: Feature Support

Item	Capability	Reference	Support	Status	Comment
11/1	Request supported features	[1] 4.3.4	M
11/2	Respond to supported features requests	[1] 4.3.4	M
11/3	Request extended features mask	[1] 4.3.4	C 2		C 2: Mandatory IFa feature requiring another features page (a feature with an LMP feature number greater than 63 in Table 3 .1: Mapping of LMP Feature Bits to ICS Items) is supported, otherwise Optional.
11/4	Respond to extended features Request	[1] 4.3.4	C 2		C 2: Mandatory IFa feature requiring another features page (a feature with an LMP feature number greater than 63 in Table 3 .1: Mapping of LMP Feature Bits to ICS Items) is supported, otherwise Optional.

Table 12: Name Information

Item Capability Reference Support Status Comment

12/1	Request name information	[1] 4.3.5	M
12/2	Respond to name requests	[1] 4.3.5	M

Table 13: Role Switch

Prerequisite: LMP 2/6 "Role switch"

Item	Capability	Reference	Support	Status	Comment
13/1	Request role switch	[1] 4.4.2	O
13/2	Accept role switch requests	[1] 4.4.2	M

Table 14: Detach

Item	Capability	Reference	Support	Status		Comment
14/1	Detach connection	[1] 4.1.2	M

Table 14a: Setting up and Removing Enhanced Date Rate ACL Connection

Item	Capability	Reference	Support Status	Comment
14a/1	Enter Enhanced Data Rate	[1] 4.1.11	C.1 v	C.1: Mandatory IF LMP 2/17 "Enhanced Data Rate ACL (2 Mb/s mode)", otherwise Excluded.
14a/2	Exit Enhanced Data Rate	[1] 4.1.11	C.1	C.1: Mandatory IF LMP 2/17 "Enhanced Data Rate ACL (2 Mb/s mode)", otherwise Excluded.

Table 14b: Setting up and Removing Enhanced Data Rate eSCO Connection

Item	Capability	Reference	Support Status	Comment
14b/1	Enter and exit eSCO using Enhanced Data	[1] 4.6.2		C.1: Mandatory IFLMP2/18 "Enhanced Data Rate eSCO(2 Mb/s mode)",
	Rate Packets			otherwise Excluded

C.1

Table 15: Hold Mode

Prerequisite: LMP 2/7 "Hold mode"
Item Capability Reference Support Status Comment

Table 16: Sniff Mode

Prerequisite: LMP 2/8 "Sniff mode"

Item	Capability	Reference	Support	Status	Comment
16/2	Request sniff mode	[1] 4.5.3, 4.5.3.2	O
16/3	Respond to sniff mode requests (renegotiate or reject)	[1] 4.5.3.2	M
16/5	Request un-sniff	[1] 4.5.3.2	C.1		C.1: Mandatory IF LMP 16/2 "Request sniff mode", otherwise Optional.
16/6	Accept un-sniff requests	[1] 4.5.3.2	M
16/7	Sniff Subrating Mode	[1] 4.5.3.2	M

Table 18: Power Control

Item	Capability	Reference	Support	Status	Comment
18/1	Request to Increase Power	[1] 4.1.3	C.1		C.1: Mandatory IF LMP 2/13a "Power Control Requests", otherwise Excluded.
18/2	Request to Decrease Power	[1] 4.1.3	C.1		C.1: Mandatory IF LMP 2/13a "Power Control Requests", otherwise Excluded.
18/3	Respond when max power reached	[1] 4.1.3	C 2		C 2: Mandatory IF LMP 2/10 "Power Control", otherwise Excluded.
18/4	Respond when min power reached	[1] 4.1.3	C 2		C 2: Mandatory IF LMP 2/10 "Power Control", otherwise Excluded.
18/5	Request to increment power a single step	[1] 4.1.3.1.1	C.3		C.3: Mandatory IF LMP 2/20 "Enhanced Power Control", otherwise Excluded.
18/6	Request to decrease power a single step	[1] 4.1.3.1.1	C.3		C.3: Mandatory IF LMP 2/20 "Enhanced Power Control", otherwise Excluded.

18/8	Respond to increment power a single step	[1] 4.1.3.1.2	C.3	C.3: Mandatory IF LMP 2/20 "Enhanced Power Control", otherwise Excluded.
18/9	Respond to decrease power a single step	[1] 4.1.3.1.2	C.3	C.3: Mandatory IF LMP 2/20 "Enhanced Power Control", otherwise Excluded.
18/10	Respond to go to max power	[1] 4.1.3.1.2	C.3	C.3: Mandatory IF LMP 2/20 "Enhanced Power Control", otherwise Excluded.

Table 19: Link Supervision Timeout

Item	Capability	Reference	Support	Status Comment
19/1	Set link supervision timeout value	[1] 4.1.6	O
19/2	Accept link supervision timeout setting	[1] 4.1.6	M

Table 20: Quality of Service

Item	Capability	Reference	Support	Status	Comment
20/1	Channel quality driven change between DMand DH packet types	[1] 4.1.7	C.1		C.1: Mandatory IF LMP 2/11 "Channel quality driven data rate", otherwise Optional.
20/2	Force/Request change of Qualityof Service	[1] 4.1.8, 4.1.8.1	M
20/3	Request change of Qualityof Service	[1] 4.1.8, 4.1.8 2	M

Table 21: SCO Links

Prerequisite: LMP 2/12 "SCO link"

Item	Capability	Reference	Support	Status	Comment
21/1	Initiate SCO links , as Central	[1] 4.6.1, 4.6.1.1	O
21/2	Initiate SCO links , as Peripheral	[1] 4.6.1, 4.6.1 2	O
21/3	Accept SCO links	[1] 4.6.1, 4.6.1.1, 4.6.1.2	O
21/4	Remove SCO links , as Central	[1] 4.6.1, 4.6.1.5	C.1		C.1: Mandatory IF LMP 21/1 "Initiate SCO links , as Central", otherwise Optional.
21/5	Remove SCO links , as Peripheral	[1] 4.6.1, 4.6.1.5	C 2		C 2: Mandatory IF LMP 21/2 "Initiate SCO links , as Peripheral", otherwise Optional.
21/6	Negotiate SCO link parameters , as Central	[1] 4.6.1, 4.6.1.3	C.3		C.3: Mandatory IF LMP 21/1 "Initiate SCO links , as Central" OR LMP 21/3 "Accept SCO links", otherwise Optional.
21/7	Negotiate SCO link parameters ,	[1] 4.6.1, 4.6.1.4	C.4		C.4: Mandatory IF LMP 21/2 "Initiate SCO links , as Peripheral" OR LMP 21/3
	as Peripheral				"Accept SCO links", otherwise Optional.

Table 22: Multi-Slot Packets

Item	Capability	Reference	Support	Status	Comment
22/1	Accept maximum allowed number of slots to be used	[1] 4.1.10	C.1		C.1: Mandatory IF LMP 2/1 "3-slot packets" OR LMP 2/2 "5-slot packets", otherwise Optional.
22/2	Request maximum number of slots to be used	[1] 4.1.10	C.1		C.1: Mandatory IF LMP 2/1 "3-slot packets" OR LMP 2/2 "5-slot packets", otherwise Optional.
22/3	Accept request of maximum number of slots tobe used	[1] 4.1.10	C.1		C.1: Mandatory IF LMP 2/1 "3-slot packets" OR LMP 2/2 "5-slot packets", otherwise Optional.

Table 23: Paging Scheme

Prerequisite: LMP 2/30 "Paging Parameter Negotiation"

Item	Capability	Reference	Support	Status Comment
23/1	Request page mode to use	[1] 4.1.9, 4.1.9.1	M
23/2	Accept suggested page mode	[1] 4.1.9, 4.1.9.1	M
23/3	Request page scan mode to use	[1] 4.1.9, 4.1.9.2	M
23/4	Accept suggested page scan mode	[1] 4.1.9, 4.1.9.2	M

Table 24: Connection Establishment

Item	Capability	Reference	Support	Status	Comment
24/1	Create connection for higher layers	[1] 4.1.1	M
24/2	Respond to requests to establish connections for higher layers	[1] 4.1.1	M
24/3	Indicate that link set-up is completed	[1] 4.1.1	M

Table 25: Test Mode

Item	Capability	Reference	Support	Status Comment
25/1	Activate test mode	[1] 4.7.1	O
25/2	Ability to reject activation of test mode if test mode is disabled	[1] 4.7.1	M
25/3	Control test mode	[1] 4.7.2	O
25/4	Ability to reject test mode control commands if test mode is disabled	[1] 4.7.2	M

Table 26: Adaptive Frequency Hopping

Item	Capability	Reference	Support	Status	Comment
26/1	Support ofAFH switch as Central	[1] 4.1.4	O
26/2	Support ofAFH switch as Peripheral	[1] 4.1.4	O
26/4	Support of Channel Classification reporting as Peripheral	[1] 4.1.5	C.2		C.2: Optional IF LMP 26/2 "Support ofAFH switch as Peripheral", otherwise Excluded.
26/4a	Support of Channel Classification reporting as Central	[1] 4.1.5	C.4		C.4: Optional IF LMP 26/1 "Support ofAFH switch as Central", otherwise Excluded.
26/5	Support channel classification from host	[1] 4.1.5	C.3		C.3: Mandatory IF LMP 26/1 "Support ofAFH switch as Central" OR LMP 26/4 "Support of Channel Classification reporting as Peripheral", otherwise Optional.
26/6	Support of Channel Classification	[1] 4.1.5	O

Table 27: Ping

Prerequisite: LMP 2/27 "Ping"

Item	Capability	Reference	Support	Status	Comment
27/1	Initiate LMP Ping	[4] 4.1.13	O
27/2	Respond to LMP Ping	[4] 4.1.13	M

Table 28: Coarse Clock Adjustment

Prerequisite: LMP 2/28 "Coarse Clock Adjustment"
Item Capability Reference Support Status Comment

Table 29: Slot Availability Mask

Prerequisite: LMP 2/29 "Slot Availability Mask"
Item Capability Reference Support Status Comment

Media Control Profile

Table 1 : Role Requirements

Item	Capability	Reference	Support	Status Comment
1/1	Media Control Server	[1] 3	C.1	C.1: Mandatoryto support at least one.
1/2	Media Control Client	[1] 4	C.1	C.1: Mandatoryto support at least one.

Table 2: Transport Requirements

Item	Capability	Reference	Support	Status			Comment
2/2	Profile supported over LE	[1] 2.4	C.1				C.1: Mandatoryto support at least one.

Table 3: Media Control Server, X.Y Versions

Prerequisite: MCP 1/1 "Media Control Server"

Item	Capability	Reference	Support	Status			Comment
3/1	Media Control Profile 1.0	[1]	M

Table 5: Service Requirements

Prerequisite: MCP 1/1 "Media Control Server"

Item	Capability	Reference	Support	Status	Comment
5/1	Media Control Service	[1] 3	O
5/2	Generic Media Control Service	[1] 3	M
5/4	Extended Advertising	[1] 6.1.1.1	M

Table 6: GAP Requirements – Media Control Server Role

Prerequisite: MCP 1/1 "Media Control Server"

Item	Capability	Reference	Support	Status	Comment
6/1	LE security mode 1	[1] 5.1	C.1		C.1: Mandatory IF MCP 2/2 "Profile supported over LE", otherwise not defined.
6/2	Bondable mode (LE)	[1] 5.1.1	C.1		C.1: Mandatory IF MCP 2/2 "Profile supported over LE", otherwise not defined.
6/3	Bonding procedure (LE)	[1] 5.1.1	C.1		C.1: Mandatory IF MCP 2/2 "Profile supported over LE", otherwise not defined.
6/4	Unauthenticated Pairing (LE security mode 1 level 2) with LE Secure Connections Pairing only	[1] 5	C.6		C.6: Mandatoryto support at least one IF MCP 2/2 "Profile supported over LE", otherwise not defined.
6/5	Authenticated Pairing (LE security mode 1 level 3) with LE Secure Connections Pairing only	[1] 5	C.6		C.6: Mandatoryto support at least one IF MCP 2/2 "Profile supported over LE", otherwise not defined.
6/6	LE security mode 1 level 4	[1] 5	C.6		C.6: Mandatoryto support at least one IF MCP 2/2 "Profile supported over LE", otherwise not defined.
6/7	Minimum 128 Bit entropy key(LE)	[1] 5	C.3		C.3: Mandatory IF MCP 6/4 "Unauthenticated Pairing (LE security mode 1 level 2) with LE Secure Connections Pairing only" OR MCP 6/5 "Authenticated Pairing (LE security mode 1 level 3) with LE Secure Connections Pairing only", otherwise not defined.

Table 7: SM Requirements – Media Control Server Role

Prerequisite: MCP 1/1 "Media Control Server"

Item	Capability	Reference	Support	Status			Comment
7/1	LE Secure Connections	[1] 5.1	C.1				C.1: Mandatoryto support at least one.

Table 8: OTP Requirements – Media Control Server Role

Prerequisite: MCP 5/3 "Object Transfer Service"
Item Capability Reference Support Status Comment

Table 9: OTS Characteristics Requirements – Media Control Server Role

Prerequisite: MCP 5/3 "Object Transfer Service"
Item Capability Reference Support Status Comment

Table 10: OTS Feature Requirements – Media Control Server Role

Prerequisite: MCP 5/3 "Object Transfer Service"
Item Capability Reference Support Status Comment

Table 11: Media Control Client, X.Y Versions

Prerequisite: MCP 1/2 "Media Control Client"

Item	Capability	Reference	Support	Status			Comment
11/1	Media Control Profile 1.0	[1]	M

Table 13: Media Control Service Support

Prerequisite: MCP 1/2 "Media Control Client"

Item	Capability	Reference	Support	Status Comment
13/1	Media Control Service	[1] 4	C.1	C.1: Mandatoryto support at least one.
13/2	Generic Media Control Service	[1] 4	C.1	v C.1: Mandatoryto support at least one.

Table 14: Media Control Service Characteristic Support Requirements

Prerequisite: MCP 13/1 "Media Control Service"

Item	Capability	Reference	Support	Status Comment
14/1	Media Player Name Characteristic	[1] 4.5.1	M
14/4	Track Changed Characteristic	[1] 4.6.1	O
14/5	Track Title Characteristic	[1] 4.5.3	O
14/6	Track Duration Characteristic	[1] 4.5.4	O
14/7	Track Position Characteristic	[1] 4.5.5	O
14/17	Media State Characteristic	[1] 4.5.22	O
14/18	Media Control Point Characteristic	[1] 4.5	O
14/19	Media Control Point Opcodes Supported Characteristic	[1] 4.5.42	O
14/22	Content Control ID Characteristic	[1] 4.5.44	O

Table 15: Media Control Point Procedure Requirements

Prerequisite: MCP 14/18 "Media Control Point Characteristic"

Item	Capability	Reference	Support	Status	Comment
15/1	PlayCurrent Track Procedure	[1] 4.5.22	O
15/2	Pause Current Track Procedure	[1] 4.5.23	O

Table 16: Generic Media Control Service Characteristic Support Requirements

Prerequisite: MCP 13/2 "Generic Media Control Service"

Item	Capability	Reference	Support	Status Comment
16/1	Media Player Name Characteristic	[1] 4.5.1	M
16/4	Track Changed Characteristic	[1] 4.6.1	O
16/5	Track Title Characteristic	[1] 4.5.3	O
16/6	Track Duration Characteristic	[1] 4.5.4	O
16/7	Track Position Characteristic	[1] 4.5.5	O
16/17	Media State Characteristic	[1] 4.5.22	O
16/18	Media Control Point Characteristic	[1] 4.5	O
16/19	Media Control Opcodes Supported Characteristic	[1] 4.5.42	O
16/22	Content Control ID Characteristic	[1] 4.5.44	O

Table 17: Media Control Point Procedure Requirements

Prerequisite: MCP 16/18 "Media Control Point Characteristic"

Item	Capability	Reference	Support	Status	Comment
17/1	PlayCurrent Track Procedure	[1] 4.5.22	O
17/2	Pause Current Track Procedure	[1] 4.5.23	O

Table 18: GAP Requirements – Media Control Client Role

Prerequisite: MCP 1/2 "Media Control Client"

Item	Capability	Reference	Support	Status	Comment
18/2	LE security mode 1	[1] 5.1	C.1		C.1: Mandatory IF MCP 2/2 "Profile supported over LE", otherwise not defined.
18/3	Bondable mode (LE)	[1] 6.2	C.1		C.1: Mandatory IF MCP 2/2 "Profile supported over LE", otherwise not defined.
18/4	Bonding procedure	[1] 6.2	C.1		C.1: Mandatory IF MCP 2/2 "Profile supported over LE", otherwise not defined.
18/5	Unauthenticated Pairing (LE security mode 1 level 2) with LE Secure Connections Pairing only	[1] 5.1	O
18/6	Authenticated Pairing (LE security mode 1 level 3) with LE Secure Connections Pairing only	[1] 5.1	O
18/7	LE security mode 1 level 4	[1] 5.1	O
18/8	Minimum 128 Bit entropy key(LE)	[1] 5.1	C.5		C.5: Mandatory IF MCP 18/5 "Unauthenticated Pairing (LE security mode 1 level 2) with LE Secure Connections Pairing only" OR MCP 18/6 "Authenticated Pairing (LE security mode 1 level 3) with LE Secure Connections Pairing only", otherwise not defined.

Table 19: SM Requirements – Media Control Client Role

Prerequisite: MCP 1/2 "Media Control Client"

Item	Capability	Reference	Support	Status			Comment
19/1	LE Secure Connections	[1] 5.1	C.1				C.1: Mandatoryto support at least one.

Table 20: OTP Requirements – Media Control Client Role

Prerequisite: MCP 13/3 "Object Transfer Service"
Item Capability Reference Support Status Comment

Table 21: OTP Procedure Requirements – Media Control Client Role

Prerequisite: MCP 13/3 "Object Transfer Service"
Item Capability Reference Support Status Comment

Media Control Service

Table 0: Versions

Item	Capability	Reference	Support	Status		Comment
0/1	Media Control Service 1.0	[1] 2.1	M

Table 1: Transport Requirements

Item	Capability	Reference	Support	Status		Comment
1/2	Service Supported over LE	[1] 1.5	C.1			C.1: Mandatoryto support at least one of the defined transports .

Table 2: Media Control Service Requirements

Item	Capability	Reference	Support	Status Comment
2/1	Media Control Service	[1] 2.1	M
2/3	Media Player Name Characteristic	[1] 3.1	M
2/7	Track Changed Characteristic	[1] 3.4	M
2/8	Track Title Characteristic	[1] 3.5	M
2/10	Track Duration Characteristic	[1] 3.6	M
2/11	Track Position Characteristic	[1] 3.7	M
2/21	Media State Characteristic	[1] 3.17	M
2/22	Media Control Point Characteristic	[1] 3.18	M

2/23	Media Control Point Opcodes Supported Characteristic	[1] 3.19	M
2/26	Content Control ID Characteristic	[1] 3 22	M

Table 3: Media Control Point Opcode Requirements

Prerequisite: MCS 2/22 “Media Control Point Characteristic”

Item	Capability	Reference	Support	Status	Comment
3/1	Play	[1] 3.18.1.1	C.1		C.1: Mandatoryto support at least one opcode.
3/2	Pause	[1] 3.18.1.2	C.1		C.1: Mandatoryto support at least one opcode.
3/5	Stop	[1] 3.18.1.5	C.1		C.1: Mandatoryto support at least one opcode.

Table 4: Media State Requirements

Item	Capability	Reference	Support	Status		Comment
4/4	Inactive	[1] 3.18.1.4	M

Table 5: GATT Requirements

Item	Capability	Reference	Support	Status Comment
5/1	Write without Response	[1] 1.4	M
5/2	Notifications	[1] 1.4	M
5/3	Write Characteristic Descriptors	[1] 1.4	M
5/4	Read Characteristic Descriptors	[1] 1.4	M

Table 6: SDP Requirements

Prerequisite: MCS 1/1 “Service Supported over BR/EDR”
Item Capability Reference Support Status Comment

Microphone Control Profile

Table 1 : Role Requirements

Item	Capability	Reference	Support	Status Comment
1/1	Microphone Device	[1] 3	C.1	C.1: Mandatoryto support at least one.
1/2	Microphone Controller	[1] 4	C.1	C.1: Mandatoryto support at least one.

Table 2: Transport Requirements

Item	Capability	Reference	Support	Status			Comment
2/2	Profile supported over LE	[1]	C.1				C.1: Mandatoryto support at least one.

Table 3: Microphone Device , X.Y Versions

Prerequisite: MICP 1/1 "Microphone Device"
Item Capability Reference Support Status Comment
3/1 Microphone Control Profile 1.0 [1] M

Table 5: Service Requirements

Prerequisite: MICP 1/1 "Microphone Device"
Item Capability Reference Support Status Comment
5/1 Microphone Control Service [1] 3 M

Table 6: GAP Requirements – Microphone Device Role

Prerequisite: MICP 1/1 "Microphone Device"

Item	Capability	Reference	Support	Status	Comment
6/1	LE security mode 1	[1] 5.1	C.1		C.1: Mandatory IF MICP 2/2 "Profile supported over LE", otherwise not defined.
6/2	Bondable mode (LE)	[1] 5.1	C.1		C.1: Mandatory IF MICP 2/2 "Profile supported over LE", otherwise not defined.
6/4	Unauthenticated Pairing (LE security mode 1 level 2) with LE Secure Connections Pairing only	[1] 5.1	C.3		C.3: Mandatoryto support at least one IF MICP 2/2 "Profile supported over LE", otherwise not defined.
6/5	Authenticated Pairing (LE security mode 1 level 3) with LE Secure Connections Pairing only	[1] 5.1	C.3		C.3: Mandatoryto support at least one IF MICP 2/2 "Profile supported over LE", otherwise not defined.
6/6	LE security mode 1 level 4	[1] 5	C.3		C.3: Mandatoryto support at least one IF MICP 2/2 "Profile supported over LE", otherwise not defined.
6/8	Minimum 128 Bit entropy key(LE)	[1] 5.1	C.6		C.6: Mandatory IF MICP 6/4 "Unauthenticated Pairing (LE security mode 1 level 2) with LE Secure Connections Pairing only" OR MICP 6/5 "Authenticated Pairing (LE security mode 1 level 3) with LE Secure Connections Pairing only", otherwise not defined.

Table 7: SM Requirements – Microphone Device Role

Prerequisite: MICP 1/1 "Microphone Device"

Item	Capability	Reference	Support	Status			Comment
7/1	LE Secure Connections	[1] 6.1	C.1				C.1: Mandatoryto support at least one.

Table 8: Microphone Controller, X.Y Versions

Prerequisite: MICP 1/2 "Microphone Controller"

Item	Capability	Reference	Support	Status		Comment
8/1	Microphone Control Profile 1.0	[1]	M

Table 10: Service Requirements

Prerequisite: MICP 1/2 "Microphone Controller"

Item	Capability	Reference	Support	Status		Comment
10/1	Microphone Control Service	[1] 4	M

Table 11: Microphone Control Service Characteristic Discovery Requirements

Prerequisite: MICP 10/1 "Microphone Control Service"
Item Capability Reference Support Status Comment
11/1 Mute [1] 4.3.1 M

Table 12: Microphone Control Service Procedures Support Requirements

Prerequisite: MICP 10/1 "Microphone Control Service"

Item	Capability	Reference	Support	Status	Comment
12/1	Configure Mute Notifications	[1] 4.4.1	O
12/2	Read Mute	[1] 4.4.1	M
12/3	Set Mute	[1] 4.4.1	O

Table 13: Audio Input Control Service Characteristic Discovery Requirements

Prerequisite: MICP 10/2 "Audio Input Control Service"
Item Capability Reference Support Status Comment

Table 14: Audio Input Control Service Procedures Requirements

Prerequisite: MICP 10/2 "Audio Input Control Service"
Item Capability Reference Support Status Comment

Table 15: Microphone Controller GATT Requirements

Prerequisite: MICP 1/2 "Microphone Controller"

Item	Capability	Reference	Support	Status	Comment
15/1	DiscoverAll Primary Services	[1] 4.1	C.1		C.1: Mandatoryto support at least one.
15/2	Discover Primary Services by Service UUID	[1] 4.1	C.1		C.1: Mandatoryto support at least one.
15/3	Find Included Services	[1] 4.1	C.2		C.2: Mandatory IF MICP 14/1 "Configure Input State Notifications" OR MICP 14/2 "Read Audio Input State"OR MICP 14/3 "Read Gain Setting Properties" OR MICP 14/4 "Read Audio Input Type" OR MICP 14/5 "Configure Audio Input Status Notifications" OR MICP 14/6 "Read Audio Input Status" OR MICP 14/7 "Set Gain Setting" OR MICP 14/8 "Mute" OR MICP 14/9 "Unmute" OR MICP 14/10 "Set Manual Gain Mode" OR MICP 14/11 "Set Automatic Gain Mode" OR MICP 14/12 "Configure Audio Input Description Notifications"OR MICP 14/13 "Read Audio Input Description" OR MICP 14/14 "Set Audio Input Description", otherwise Optional.
15/4	DiscoverAll Characteristics of a Service	[1] 4.1	C.3		C.3: Mandatoryto support at least one.
15/5	Discover Characteristics byUUID	[1] 4.1	C.3		C.3: Mandatoryto support at least one.
15/6	DiscoverAll Characteristic Descriptors	[1] 4.1	M
15/7	Read Characteristic Value	[1] 4.1	M
15/8	Write Characteristic Value	[1] 4.1	M
15/9	Notifications	[1] 4.1	M
15/10	Read Characteristic Descriptors	[1] 4.1	M
15/11	Write Characteristic Descriptors	[1] 4.1	M

Table 16: GAP Requirements – Microphone Controller Role

Prerequisite: MICP 1/2 "Microphone Controller"

Item	Capability	Reference	Support	Status	Comment
16/1	Bondable mode (LE)	[1] 5.1	C.1		C.1: Mandatory IF MICP 2/2 "Profile supported over LE", otherwise not defined.
16/3	LE security mode 1	[1] 5	C.1		C.1: Mandatory IF MICP 2/2 "Profile supported over LE", otherwise not defined.
16/4	Unauthenticated Pairing (LE security mode 1 level 2) with LE Secure Connections Pairing only	[1] 5	O
16/5	Authenticated Pairing (LE security mode 1 level 3) with LE Secure Connections Pairing only	[1] 5	O
16/6	LE security mode 1 level 4	[1] 5	O
16/7	Minimum 128 Bit entropy key	[1] 5.1	C.3		C.3: Mandatory IF MICP 16/4 "Unauthenticated Pairing (LE security mode 1 level 2) with LE Secure Connections Pairing only" OR MICP 16/5 "Authenticated Pairing (LE security mode 1 level 3) with LE Secure Connections Pairing only", otherwise not defined.

Table 17: SM Requirements – Microphone Controller Role

Prerequisite: MICP 1/2 "Microphone Controller"
Item Capability Reference Support Status Comment
17/1 LE Secure Connections [1] 6.1 C.1 C.1: Mandatoryto support at least one.

Microphone Control Service

Table 0: Versions

Item	Capability	Reference	Support	Status			Comment
0/1	Microphone Control Service 1.0	[1] 2.1	M

Table 1: Transport Requirements

Item	Capability	Reference	Support	Status		Comment
1/2	Service Supported over LE	[1] 1.5	C.1			C.1: Mandatoryto support at least one of the defined transports .

Table 2: Microphone Control Service Requirements

Item	Capability	Reference	Support	Status			Comment
2/1	Mute Characteristic	[1] 3.1.1	M

Table 3: GATT Requirements

Item	Capability	Reference	Support	Status Comment
3/1	Write Characteristic Value	[1] 1.4	M
3/2	Notifications	[1] 1.4	M
3/3	Read Characteristic Descriptors	[1] 1.4	M
3/4	Write Characteristic Descriptors	[1] 1.4	M

Table 4: SDP Requirements

Prerequisite: MICS 1/1 "Service Supported over BR/EDR"
Item Capability Reference Support Status Comment

Published Audio Capabilities Service

Table 0: X.Y Versions

Item	Capability	Reference	Support	Status			Comment
0/1	Published Audio Capabilities Service v1 .0	[1] 2	M

Table 1 : X.Y.Z Versions

Item	Capability	Reference	Support	Status		Comment
1/1	Published Audio Capabilities Service v1 .0.1	[1] 2	O

Table 2: Transport Requirements

Item	Capability	Reference	Support	Status		Comment
2/2	Service supported over LE	[1] 1.5	C.1			C.1: Mandatoryto support at least one.

Table 3: Published Audio Capabilities Service

Item	Capability	Reference	Support	Status	Comment
3/1	Sink PAC Characteristic	[1] 3.1.1	C.1		C.1: Mandatoryto support at least one.
3/2	Sink Audio Locations Characteristic	[1] 3.2.1	C.2		C.2: Optional IF PACS 3/1 "Sink PAC Characteristic", otherwise Excluded.
3/3	Source PAC Characteristic	[1] 3.3.1	C.1		C.1: Mandatoryto support at least one.
3/4	Source Audio Locations Characteristic	[1] 3.4.1	C.3		C.3: Optional IF PACS 3/3 "Source PAC Characteristic", otherwise Excluded.

Table 4: Service Requirements

Item	Capability	Reference	Support	Status	Comment
4/13	Changeable Available Audio Contexts Characteristic	[1] 3.5.1	M
4/14	Notifiable Available Audio Contexts Characteristic	[1] 3.5.1	M
4/15	Changeable Supported Audio Contexts Characteristic	[1] 3.6.1	C.11		C.11: Optional IF PACS 3/6 "Supported Audio Contexts Characteristic", otherwise Excluded.
4/16	Notifiable Supported Audio Contexts Characteristic	[1] 3.6.1	C.12		C.12: Mandatory IF PACS4/15 "Changeable Supported Audio Contexts Characteristic", otherwise Excluded.

Table 5: GAP Requirements

Item	Capability	Reference	Support	Status		Comment
5/1	Bondable mode (LE)	[1] 3	C.1			C.1: Optional IF PACS 2/2 "Service supported over LE", otherwise not defined.

Table 6: GATT Requirements

Item	Capability	Reference	Support	Status Comment
6/1	Read Characteristic Descriptors	[1] 1.4	M
6/2	Write Characteristic Descriptors	[1] 1.4	M
6/3	Notifications	[1] 1.4	M
6/4	Write Characteristic Value	[1] 1.4	M

Table 7: SDP Requirements

Prerequisite: PACS 2/1 "Service supported over BR/EDR"
Item Capability Reference Support Status Comment

Public Broadcast Profile

Table 1 : Role Requirements

Item	Capability	Reference	Support	Status	Comment
1/1	Public Broadcast Source	[2] 2.1	C.1		C.1: Mandatoryto support at least one of PBP 1/1 "Public Broadcast Source" OR PBP 1/2 "Public Broadcast Sink" OR PBP 1/3 "Public Broadcast Assistant".
1/2	Public Broadcast Sink	[2] 2.1	C.1		C.1: Mandatoryto support at least one of PBP 1/1 "Public Broadcast Source" OR PBP 1/2 "Public Broadcast Sink" OR PBP 1/3 "Public Broadcast Assistant".
1/3	Public Broadcast Assistant	[2] 2.1	C.1		C.1: Mandatoryto support at least one of PBP 1/1 "Public Broadcast Source" OR PBP 1/2 "Public Broadcast Sink" OR PBP 1/3 "Public Broadcast Assistant".

Table 2: Transport Requirements

Item	Capability	Reference	Support	Status		Comment
2/2	Profile supported over LE	[2] 2.3	M

Table 3: Major Versions (X.Y)

Prerequisite: PBP 1/1 "Public Broadcast Source"

Item	Capability	Reference	Support	Status			Comment
3/1	Public Broadcast Profile v1 .0	[2]	M

Table 5: Public Broadcast Source Role – Support Requirements

Prerequisite: PBP 1/1 "Public Broadcast Source"

Item	Capability	Reference	Support	Status	Comment
5/1	Initiator	[2] 3.1.1	M
5/2	BAP Broadcast Source	[2] 2.1	M

Table 6: Public Broadcast Source Role – Features

Prerequisite: PBP 1/1 "Public Broadcast Source"

Item	Capability	Reference	Support	Status	Comment
6/3	Public Broadcast Announcement	[2] 4	M
6/4	Standard Quality Public Broadcast Audio	[2] 4.1	M
6/6	Encrypted Broadcast Isochronous Stream	[2] 4	C 2		C 2: Mandatoryto support at least one of PBP 6/6 "Encrypted Broadcast Isochronous Stream" OR PBP 6/7 "Unencrypted Broadcast Isochronous Stream".
6/7	Unencrypted Broadcast Isochronous Stream	[2] 4	C 2		C 2: Mandatoryto support at least one of PBP 6/6 "Encrypted Broadcast Isochronous Stream" OR PBP 6/7 "Unencrypted Broadcast Isochronous Stream".
6/8	Broadcast Name AD Type	[2] 5	M

Table 7: Standard Quality Public Broadcast Audio configuration support requirements

Prerequisite: PBP 6/4 "Standard Quality Public Broadcast Audio"

Item	Capability	Reference	Support Status Comment
7/1	16_2_1 LC3– 10000 SDU Interval , unframed, 40 Max SDU Size, 2 RTN, 10 Max_Transport_Latency	[2] 4 2	M
7/3	16_2_2 LC3– 10000 SDU Interval , unframed, 40 Max SDU Size, 4 RTN, 60 Max_Transport_Latency	[2] 4 2	M

Table 8: High Quality Public Broadcast Audio configuration support requirements

Prerequisite: PBP 6/5 "High Quality Public Broadcast Audio"
Item Capability Reference Support Status Comment

Table 9: Major Versions (X.Y)

Prerequisite: PBP 1/2 "Public Broadcast Sink"

Item	Capability	Reference	Support	Status			Comment
9/1	Public Broadcast Profile v1 .0	[2]	M

Table 11: Public Broadcast Sink Role – Support Requirements

Prerequisite: PBP 1/2 "Public Broadcast Sink"

Item	Capability	Reference	Support	Status	Comment
11/1	Acceptor	[2] 3.2.1	M
11/2	BAP Broadcast Sink	[2] 3.2.1	M

Table 12: Public Broadcast Sink Role – Features

Prerequisite: PBP 1/2 "Public Broadcast Sink"

Item	Capability	Reference	Support	Status			Comment
12/1	Standard Quality Public Broadcast Audio	[2] 4.1	M

Table 13: Standard Quality Public Broadcast Audio configuration support requirements

Prerequisite: PBP 12/1 "Standard Quality Public Broadcast Audio"

Item Capability Reference Support Status Comment

13/1 16_2_1 LC3– 10000 SDU Interval , unframed, 40 Max SDU Size, 2 RTN, 10 Max_Transport_Latency [2] 4 2 M
13/2 24_2_1 LC3– 10000 SDU Interval , unframed, 60 Max SDU Size, 2 RTN, 10 Max_Transport_Latency [2] 4 2 M
13/3 16_2_2 LC3– 10000 SDU Interval , unframed, 40 Max SDU Size, 4 RTN, 60 Max_Transport_Latency [2] 4 2 M
13/4 24_2_2 LC3– 10000 SDU Interval , unframed, 60 Max SDU Size, 4 RTN, 60 Max_Transport_Latency [2] 4 2 M
Table 14: High Quality Public Broadcast Audio configuration support requirements
Prerequisite: PBP 12/2 "High Quality Public Broadcast Audio"
Item Capability Reference Support Status Comment

Table 15: Major Versions (X.Y)

Prerequisite: PBP 1/3 "Public Broadcast Assistant"
Item Capability Reference Support Status Comment
15/1 Public Broadcast Profile v1 .0 [2] M V

Table 17: Public Broadcast Assistant Role – Support Requirements

Prerequisite: PBP 1/3 "Public Broadcast Assistant"

Item	Capability	Reference	Support	Status	Comment
17/1	Commander	[2] 3.3.1	M
17/2	BAP Broadcast Assistant	[2] 3.3.1	M

Radio

Table 1 : RF Capabilities
