23. Reusable Space Special Upgrade Process
This function is an upgrade process designed for small capacity solutions.
23.1. Compressed Resource Package Method
23.1.1. Flow Chart
23.1.2. Sample Code
public class ReuseSpaceOTADemo {
private WatchManager watchManager;
private OTAManager otaManager;
private boolean isOTAInitOk;
private OnWatchCallback onWatchCallback;
void init(@NonNull Context context) {
//WatchManager is a subclass of WatchOpImpl, must configure sdk in 1.3
watchManager = WatchManager.getInstance();
//Initialize OTA manager
otaManager = new OTAManager(context);
otaManager.addOnRcspCallback(new OnRcspCallback() {
@Override
public void onRcspInit(BluetoothDevice bluetoothDevice, boolean b) {
isOTAInitOk = b;
}
@Override
public void onMandatoryUpgrade(BluetoothDevice bluetoothDevice) {
isOTAInitOk = true;
}
});
}
void destroy() {
isOTAInitOk = false;
releaseCallback();
if (null != otaManager) {
otaManager.release();
otaManager = null;
}
}
void releaseCallback() {
if (null != onWatchCallback) {
watchManager.unregisterOnWatchCallback(onWatchCallback);
onWatchCallback = null;
}
}
void tryToUpdateResource() {
if (null == watchManager || null == otaManager || !isOTAInitOk) return;
//resourcePath: Resource path (zip compressed package)
final String resourcePath = "Required updated resource compressed package path";
onWatchCallback = new OnWatchCallback() {
@Override
public void onRcspInit(BluetoothDevice device, boolean isInit) {
//Callback RCSP protocol layer initialization result
if (!isInit) { //Initialization failed, disconnect device connection
releaseCallback();
watchManager.getBluetoothHelper().disconnectDevice(device);
}
}
@Override
public void onWatchSystemInit(int code) {
final BluetoothDevice device = watchManager.getConnectedDevice();
//Callback watch system initialization result
if (code == WatchError.ERR_NONE) {
final DeviceInfo deviceInfo = watchManager.getDeviceInfo(device);
if (null != deviceInfo && deviceInfo.getExpandMode() != WatchConstant.EXPAND_MODE_NONE) {
onResourceUpdateUnfinished(device);
return;
}
return;
}
onRcspInit(device, false);
}
@Override
public void onResourceUpdateUnfinished(BluetoothDevice device) {
//Callback resource not updated
updateResource(resourcePath);
}
};
watchManager.registerOnWatchCallback(onWatchCallback);
//Normal mode
updateResource(resourcePath);
}
void updateResource(String resourcePath) {
//OnUpdateResourceCallback: Update resource progress listener
watchManager.updateWatchResource(resourcePath, new OnUpdateResourceCallback() {
@Override
public void onStart(String filePath, int total) {
//Callback start
//filePath -- Resource file path
//total -- Total number of files to update
}
@Override
public void onProgress(int index, String filePath, float progress) {
//Callback progress
//index -- Index (starting from 0)
//filePath -- Resource file path
//progress -- Update progress
}
@Override
public void onStop(String otaFilePath) {
//Callback update end
//otaFilePath: Firmware upgrade file path
//If firmware upgrade file is not null, it means OTA upgrade is required
if (!TextUtils.isEmpty(otaFilePath)) {
updateFirmware(otaFilePath);
return;
}
//Resource update completed
onError(WatchError.ERR_NONE, "Update Resource Successfully");
}
@Override
public void onError(int code, String message) {
//Callback error event
//code -- Error code (refer to WatchError)
//message -- Error message
releaseCallback();
}
});
}
void updateFirmware(String otaFilePath) {
if (null == otaManager || !isOTAInitOk || TextUtils.isEmpty(otaFilePath)) return;
final BluetoothOTAConfigure configure = otaManager.getBluetoothOption();
configure.setFirmwareFilePath(otaFilePath);
otaManager.configure(configure);
otaManager.startOTA(new IUpgradeCallback() {
@Override
public void onStartOTA() {
}
@Override
public void onNeedReconnect(String s, boolean b) {
}
@Override
public void onProgress(int i, float v) {
}
@Override
public void onStopOTA() {
//Upgrade completed
onError(OTAError.buildError(ErrorCode.ERR_NONE));
}
@Override
public void onCancelOTA() {
}
@Override
public void onError(BaseError baseError) {
if (null == baseError) return;
//Firmware program update completed, need to reconnect device to force update resources
if (baseError.getSubCode() == ErrorCode.SUB_ERR_NEED_UPDATE_RESOURCE) {
String reconnectDeviceMac = baseError.getMessage();
//Reconnect device
reconnectDevice(reconnectDeviceMac);
return;
}
releaseCallback();
}
});
}
void reconnectDevice(String address) {
if (null == watchManager || !CHexConver.checkBluetoothAddress(address)) return;
final BluetoothHelper btHelper = watchManager.getBluetoothHelper();
btHelper.addBluetoothEventListener(new BluetoothEventListener() {
@Override
public void onBtDiscoveryStatus(boolean bBle, boolean bStart) {
if (!bStart) {
btHelper.removeBluetoothEventListener(this);
}
}
@Override
public void onBtDiscovery(BluetoothDevice device, BleScanMessage bleScanMessage) {
if (null == device) return;
if (TextUtils.equals(device.getAddress(), address)) {
//Stop Bluetooth search
btHelper.getBluetoothOp().stopBLEScan();
btHelper.addBluetoothEventListener(new BluetoothEventListener() {
@Override
public void onConnection(BluetoothDevice device, int status) {
if (null == device) return;
if (status != BluetoothConstant.CONNECT_STATE_CONNECTING && TextUtils.equals(device.getAddress(), address)) {
btHelper.removeBluetoothEventListener(this);
if (status == BluetoothConstant.CONNECT_STATE_CONNECTED) {
//Reconnection successful
return;
}
//Reconnection failed
releaseCallback();
}
}
});
if (!btHelper.connectDevice(device, bleScanMessage)) {
//Reconnection device failed
releaseCallback();
}
}
}
});
//Perform device search operation
btHelper.getBluetoothOp().startBLEScan(60 * 1000);
}
}
